Rialto 600

Description

2.1-Channel Compact Amplifier with Digital-to-Analog Converter (DAC)

Building upon the success of the Rialto 400 amplifier/DAC with the addition of Volume Control, dual-digital inputs, plus direct or remote IR and RS-232 control, the Rialto 600 is the benchmark solution in local zone audio amplification. A breakthrough, compact, high-powered amplifier with an audiophile-grade Wolfson Digital-to-Analog Converter, the Rialto 600 with variable volume output is an ideal zone solution for local speakers and source playback, analog or digital.

AudioControl’s Rialto 600 provides dramatic audio quality to improve performance in any localized audio zone. Upgrade the sound of analog or digital television audio, including gaming, by adding the Rialto 600 to external speakers. Improve streamed music sources like SONOS, HEOS, and others by transferring their digital signals for ultra-precise decoding by the onboard Wolfson DAC and amplification by the Rialto 600’s authoritative 100 watts into 8 Ohms or 200 watts into 4 Ohms. Low-impedance stable down to 3.6 Ohms, the Rialto may also be bridged for use as a 400-watt monoblock.

The feature-packed Rialto 600 is designed, engineered, and manufactured for the residential and Pro Audio custom installation markets in the rainforest of the Northwest USA, somewhere North of Seattle, and is backed by AudioControl’s renowned 5-year warranty.

Rialto 600

Product form

2.1 Channel Compact Amplifier with Audiophile-grade Wolfson Digital to Analog Converter

  • 2 channels with bridged mono and subwoofer mono preamp outputs
  • 100w into 8 Ohms, 200W into 4 Ohms, 400W mono into 8 Ohms
  • RS-232 & IR Control
  • High-quality Wolfson DAC 16-/24-bit, 32 to 192 kHz Sampling Frequencies

SKU: 8611230

    Description

    2.1-Channel Compact Amplifier with Digital-to-Analog Converter (DAC)

    Building upon the success of the Rialto 400 amplifier/DAC with the addition of Volume Control, dual-digital inputs, plus direct or remote IR and RS-232 control, the Rialto 600 is the benchmark solution in local zone audio amplification. A breakthrough, compact, high-powered amplifier with an audiophile-grade Wolfson Digital-to-Analog Converter, the Rialto 600 with variable volume output is an ideal zone solution for local speakers and source playback, analog or digital.

    AudioControl’s Rialto 600 provides dramatic audio quality to improve performance in any localized audio zone. Upgrade the sound of analog or digital television audio, including gaming, by adding the Rialto 600 to external speakers. Improve streamed music sources like SONOS, HEOS, and others by transferring their digital signals for ultra-precise decoding by the onboard Wolfson DAC and amplification by the Rialto 600’s authoritative 100 watts into 8 Ohms or 200 watts into 4 Ohms. Low-impedance stable down to 3.6 Ohms, the Rialto may also be bridged for use as a 400-watt monoblock.

    The feature-packed Rialto 600 is designed, engineered, and manufactured for the residential and Pro Audio custom installation markets in the rainforest of the Northwest USA, somewhere North of Seattle, and is backed by AudioControl’s renowned 5-year warranty.

    • FEATURES
    • SPECIFICATIONS
    • RESOURCES
    • Compact Amplifier and Digital Analog Converter (DAC)
    • Audiophile-grade Wolfson Digital Analog Converter (DAC)
    • 2 x 100 watts into 8 Ohms, 200 watts into 4 Ohms
    • 400 watts Mono-bridgeable
    • Stable Down to 3.6 Ohms
    • Preamp Volume Control Via Direct and Remote IR and RS-232
    • Source Switching Via Direct or Remote IR and RS-232
    • Includes Remote Control
    • 2 x TOSLINK & 2 x Coaxial Digital Inputs with Analog Stereo Inputs
    • Subwoofer Mono-summed Output
    • AudioControl Patented AccuBASS ™ Bass Response
    • Built-in, Selectable Electronic Crossover Points
    • 12v Trigger Input
    • 3.5 mm Headphone Output
    • 5-way Binding Posts
    • Compact Size at 8.5” W x 5.4” D x 2.9” H
    INPUTS
    Digital Inputs: Optical TOSLINK x 2, Coaxial S/PDIF 75 ohms x 2
    Analog Inputs: Stereo RCA x 1
    Input Sensitivity: 230mV
    Signal Sense Trigger Minimum: 10mV
    CONTROL
    12 Volt Trigger Inputs: 1 (mini jack)
    IR Inputs: 1 (mini jack)
    IR Outputs: 1 (mini jack)
    RS-232 Serial Control: Yes
    OUTPUTS
    Amplifier Channels: 2
    Power Output (8Ω): 100W per channel
    Power Output (4Ω): 200W per channel
    Minimum Speaker Load: 4Ω
    Preamp Outputs: Mono RCA Subwoofer, Mono RCA Bridged
    GENERAL
    Power Consumption (typical usage): 40W
    Power Consumption (maximum): 520W
    Line Voltage: 100-120VAC/200‐240VAC Switchable
    PERFORMANCE
    Signal-to-Noise Ratio: >95dB
    Frequency Response: 20Hz-20kHz
    Total Harmonic Distortion: 0.09%
    WEIGHT & DIMENSIONS
    Dimensions: 8.5” W x 5.4” D x 2.9” H
    Weight: 6.0lbs (2.7kg)
     IN THE BOX
    Rialto 600, RT-1 Remote, Power Cord, Optical TOSLINK Cable, User Manual, Warranty

    MANUAL
    DATA SHEET
    DRIVERS
    AUTOMATION TABLE
    IR LEARNING
    SLEEP MODE & SIGNAL SENSE
