Architect P2660

Description



The Architect ‘P’ Series superbly complements AudioControl’s popular high-power Architect multi-zone amplifier series with an industry leading 100 Watts RMS per channel into 8 ohms, 200 watts per channel into 4 ohms; all channels driven.

The P2660 uses a cool running proprietary design, including AudioControl’s LightDriveTM anti-clipping protection and features input busing capability, output pass-thru, master 12V trigger in/out plus local 12V trigger inputs on all zones, signal sensing as well plus coax SPDIF inputs for digital sources.

Available in a robust black powder coat finish, the Architect Model P2660 is designed, engineered and manufactured at AudioControl’s manufacturing facilities located in Seattle, USA. The Architect ‘P’ series comes with AudioControl’s legendary 5-year warranty and is available exclusively to the residential custom install and pro audio markets through AudioControl authorized dealers.

Architect P2660

Product form

16-Channel High-Power Multi-Zone Amplifier

  • 16 channels, up to 8 Zones
  • 100W at 8 Ohms, 200W at 4 Ohms
  • Bridgeable outputs
  • Individual Local and Grouped BUS inputs

SKU: 8611360

    Description



    The Architect ‘P’ Series superbly complements AudioControl’s popular high-power Architect multi-zone amplifier series with an industry leading 100 Watts RMS per channel into 8 ohms, 200 watts per channel into 4 ohms; all channels driven.

    The P2660 uses a cool running proprietary design, including AudioControl’s LightDriveTM anti-clipping protection and features input busing capability, output pass-thru, master 12V trigger in/out plus local 12V trigger inputs on all zones, signal sensing as well plus coax SPDIF inputs for digital sources.

    Available in a robust black powder coat finish, the Architect Model P2660 is designed, engineered and manufactured at AudioControl’s manufacturing facilities located in Seattle, USA. The Architect ‘P’ series comes with AudioControl’s legendary 5-year warranty and is available exclusively to the residential custom install and pro audio markets through AudioControl authorized dealers.

    • FEATURES
    • SPECIFICATIONS
    • RESOURCES
    • 16 Channels of High Power and AudioControl Performance
    • 100 watts per Channel at 8 Ohms (All Channels Driven)
    • 200 watts per Channel at 4 Ohms (All Channels Driven)
    • Bridgeable as an 8 channel amplifier at 400 watts
    • Low Standby Current Draw of Less Than 1 Watt
    • Compact Design Fits into 2 Rack Spaces
    • LightDriveTM Anti-Clipping Protection Circuitry
    • 12v Trigger Input and Output
    • 2 x Input Buses (Digital and Analog)
    • Local Zone Input Trigger
    • Signal-Sensing On All Channels
    • Input Busing and Level Controls
    • Mono-switch for Improved Bridging
    • Beefy Rack Mount Brackets Included
    • Five Year AudioControl Warranty
    INPUTS
    Inputs: 8 Stereo Local Analog Inputs, 1 Stereo Bus Digital Input, 1 Stereo Bus Analog Input
    Input Sensitivity: Variable 0-1 Vrms
    Analog Input Sensitivity: 1 Vrms for full output; level at maximum
    AC POWER REQUIREMENTS
    Standby: 0.9W
    Idle (main power on, all channels off): 42W
    All channels active: 90W
    All channels 1/8th rated power: 338W
    Full power (20A residential service limited): 2400W
    Protection: clipping, short circuit, thermal, ultrasonic, DC offset, stable into reactive or mismatched loads
    OUTPUTS
    Amplifier Channels: 16
    1 Stereo Bus Analog Output
    Power Output (8Ω): 100W per channel
    Power Output (4Ω): 200W per channel
    Power Output (Bridged Mono): 400W
    Minimum Speaker Load: 4Ω
    BTU/HR OUTPUT
    Standby: 3.1 BTU/hr
    Idle (main power on, all channels off): 144 BTU/hr
    All channels active: 307 BTU/hr
    All channels 1/8th rated power: 415 BTU/hr
    Full power (20A residential service limited): 2124 BTU/hr
    PERFORMANCE
    Damping Factor: >300
    Signal to Noise: >105 dB, (A-wtd, ref full output)
    Crosstalk: >80 dB @ 1kHz
    Gain: 30 dB
    Analog Input Sensitiviy: 1 Vrms for full output, level at maximum
    DAC Specifications: 32 – 96 kHz sample rate, 16/24 bit depth
    WEIGHT & DIMENSIONS
    Dimensions: 19″ W (w/rack ears) 17” W (w/no rack ears) x 15.5” D x ” H 3.5″ (2U)
    Weight: 20.5 lbs (9.3 kg)
    CONTROL
    Remote Power Trigger: +12 VDC or Dry Contact Closure, 2 x 1/8″ TS mono in/out
    IN THE BOX
    Architect Model P2660, Speaker Connectors, Remote Connector, Power Cord, Manual, Warranty

    MANUAL
    DATA SHEET
